Filtaworx FED400
Electric Drive Self Cleaning Water Filter
Electric motor drive automatic filter. DN400. Flow rate 1,100 m³/h.
Key Specifications
Filter Sizes
DN400
Flow Range
1,100 m³/h
Drive Type
Electric
Filter Area
12,170 cm²
Product Overview
The Filtaworx FED400 uses an electric gear motor for precise backwash control.
Filters in this range are also known as automatic backwash filters — the screen is cleaned in place by an automatic backwash cycle while flow continues uninterrupted.
The cleaning cycle, what triggers it and what it costs in water and time are set out in how automatic self-cleaning filters work.
Features & Advantages
Electric Gear Motor Drive
Precise Backwash Control
Self-Reversing Drive Shaft
Suction Nozzle Cleaning
Wide Pressure Range: 0.5-16 bar
PLC Controller Integration
Specifications
| Specification | Value |
|---|---|
| drive Type | Electric |
| filter Sizes | DN400 |
| flow Rate | 1,100 m³/h |
| filter Area | 12,170 cm² |
| filtration Degree | 30, 50, 80, 100, 120, 150, 200, 300, 400, 800 µm |
| operating Pressure | 0.5–16 bar |
| max Temperature | 65 °C |
| rinse Cycle | 15–17 seconds |
Other screen sizes available on request — the grades above are the standard range.
Data & Weights
| Model | DN | Flow rate | Filter area | Weight (Std) | Weight (HP) |
|---|---|---|---|---|---|
| FED400 | DN400 | 1,100 m³/h | 12,170 cm² | 345 kg | 742 kg (full) |
Dimensions
| Dimension | Value |
|---|---|
| Inlet / Outlet | DN400 (16") |
| Body Ø | 457 mm |
| Centre distance | 1,270 mm |
| Body O/A length | 2,531 mm |
| Filtration area | 12,170 cm² |
| Flow rate | 1,100 m³/h (4,843 gpm) |
Shipping & weights
| Item | Value |
|---|---|
| Packed dimensions (L × W × H) | 340 × 63 × 83 cm |
| Shipping volume | 1.3 m³ |
| Weight — standard | 340 kg (750 lb) |
| Weight — high pressure | 380 kg (840 lb) |
