Filtaworx FW100EX
Automatic Self Cleaning Water Filter
Large piston-driven automatic filter. DN100. Flow rate 100 m³/h. Hydraulic drive.
Key Specifications
Filter Sizes
DN100
Flow Range
100 m³/h
Drive Type
Hydraulic
Filter Area
5,600 cm²
Product Overview
The Filtaworx FW100EX is a large-format automatic self-cleaning screen filter with 5,600 cm² of filtration area.
Filters in this range are also known as automatic backwash filters — the screen is cleaned in place by an automatic backwash cycle while flow continues uninterrupted.
The cleaning cycle, what triggers it and what it costs in water and time are set out in how automatic self-cleaning filters work.
Features & Advantages
Specifications
| Specification | Value |
|---|---|
| drive Type | Hydraulic |
| filter Sizes | DN100 |
| flow Rate | 100 m³/h |
| filter Area | 5,600 cm² |
| filtration Degree | 30, 50, 80, 100, 120, 150, 200, 300, 400, 800 µm |
| operating Pressure | 2.0–10 bar |
| max Temperature | 65 °C |
| rinse Cycle | 15–17 seconds |
Other screen sizes available on request — the grades above are the standard range.
Data & Weights
| Model | DN | Flow rate | Filter area | Weight (Std) | Weight (HP) |
|---|---|---|---|---|---|
| FW100EX | DN100 | 100 m³/h | 5,600 cm² | 90 kg | 111 kg |
Dimensions
| Dimension | Value |
|---|---|
| Inlet / Outlet | DN100 (4") |
| Body Ø | 273 mm |
| Centre distance | 900 mm |
| Body O/A length | 1,390 mm |
| Filtration area | 5,600 cm² |
| Flow rate | 100 m³/h (440 gpm) |
Shipping & weights
| Item | Value |
|---|---|
| Packed dimensions (L × W × H) | 220 × 56 × 71 cm |
| Shipping volume | 0.88 m³ |
| Weight — standard | 90 kg (200 lb) |
| Weight — high pressure | 111 kg (245 lb) |
Typical Applications
